Satmap Active 10 Plus GPS
Satmap Active 10 Plus GPS
Never get lost again! Like an electronic version of a dummies' guide, the Satmap Active 10 Plus is designed with the user in mind.
The Satmap Active 10 Plus follows on from the success of the Satmap Active 10.
The Active 10 Plus unit retains the same features, functionality and performance as the original Active 10 but with the addition of a 1:5 million World Base map and a full GB Postcode search.
Along with the Satmap Active 10 unit, a USB cable, a carry case, lanyard and 3 x AA batteries, the bundle also includes:
- Satmap Online Route Planner
- Online Route Share Network
- Rechargeable Battery and Charger
- 1/3 Off Digital Map Voucher
Easy to use and revolutionary - rarely are these two concepts spoken in the same breath. The Satmap Active 10 set the benchmark for navigational devices, straightforward operation, effective design and, most importantly, no computer needed; now the SatMap Active 10 Plus is out to beat its own benchmark.
Kiss goodbye to that A-Z atlas - no wait ... kiss goodbye to that world atlas too!
Plug & Play Mapping
So simple to use with no computer necessary, the Satmap Active 10 Plus is the definition of Plug and Play. Maps are supplied on SD cards that simply plug straight into the Satmap Active10 Plus .
Absolutely no computer or other equipment needed to get started
Purpose-built for the Great Outdoors
Waterproof and shockproof, the Satmap Active 10 Plus is designed to be used outside not to be kept inside for fear of breaking.
Featuring some of the most advanced navigation technology available, the Active10 Plus puts a new spin on venturing out in the great outdoors.
- Electronic compass
- Direction indicator
- On-board route planning
- Map orientation
Version 1.4 Software offers many new features and functions including:
- Geocaching: Geocaching with the Active 10 is now even easier, it is now possible to download caches from sites like Geocaching.com complete with the full set of hints and tips.
- Google Earth: Google Earth is a great resource and now the Active 10 can interact with it more effectively, allowing routes to be created, downloaded and uploaded between Google Earth and the Active 10.
- Map Toggling: Satmap has always been able to display multiple map scales, though on previous versions of software, these maps were viewed by zooming in and out, now Satmap has introduced the Map Toggle feature. The Map Toggle feature allows users to toggle between different maps available at the point with a click of a button without zooming.
- Track Up: For users who like to orientate the map to the ground, the Track Up feature is invaluable. V1.4 now moves the 'You Are Here' location point towards the bottom of the screen, thereby allowing users to see more of the map ahead. Additionally, users can now use Planning Mode when using a map in the Track Up display.
- Hibernate Mode: Many users just want to see where they are on a map without logging a snail trail. Hibernate Mode allows users to do just that and in so doing gives the added benefit of huge power savings. With the device in Hibernate Mode, it stores the satellite data for up to 8 hours and leaves the operating system on stand by. When users want their position, they press the On button and are presented with an instant map screen and a position fix in a few seconds. A unit on “stand by” will give over 100 hours of usage.
- Red Light Option: For users who are keen to protect their night vision, V1.4 now offers a red light option on the backlight. For those who prefer the normal backlight, there are now much lower settings, ensuring you are maximising battery life.
- Routes & POIs: A new option allows users to hide inactive routes more effectively without cluttering the map, the new folder structure makes storage of routes easier. POIs now come with a library of different icons, making it much faster to identify POI types.
- Distance Measuring Tool: It is now easier to calculate the distance between two points on the Active 10, the Mark function allows users to establish the distance and bearing between any two points, no matter how remote.
- WAAS / EGNOS Enabled: Where available, the accuracy of the Active 10 is now enhanced by WAAS / EGNOS compatibility, which is indicated on the unit by the satellite lock changing from green to orange.
Features
Real Maps - A wide range containing high-quality Ordnance Survey supported maps |
|
Clear Navigation - The intelligence of the Active 10 makes finding your way simple |
|
Trip Statistics - Automatically records your route data so you always know where you’ve been |
|
Personal - Add favourite places, POIs & other important data and share via the internet with other users |
|
Electronic Compass - Internal electronic compass works like a standard compass |
|
Internet Links - Connect via USB to download maps or share content |
|
International Maps - A wide and growing range available |
|
Guide Book - Multi-media POIs bring your routes to life |
|
Easy to use - No computer is needed, just insert a map and go |
Dimensions
- Height: 13 cm
- Width: 7.5 cm
- Depth: 3 cm
- Weight: 185 g
Click image to resize
Technical Specification
- Toughened, impact-resistant ABS casing with all-weather capability
- Day/night functionality
- SiRF Star III GPS receiver
- Integrated 18-mm patch antenna
- In-built 2-axis electronic compass
- 3.5-inch LCD TFT backlit colour screen
- Microsoft CE operating system
- In-built lithium polymer battery charger
- Power source options:
- 3 x AA size standard alkaline batteries
- Large 3.7 v/2900 mAh lithium polymer ‘smart’ battery
- 240 v/120 v mains supply
- 12v DC vehicle adaptor (cigarette lighter) - Dual-function USB 2.0:
- Power input
- Data transfer via PC - SD card reader allowing expandable memory (up to 4 GB currently; Note: memory only limited by capacity of available SD cards)
- ARM 9 processor
- In-built multi-media player
- 128 MB RAM
- Interchangeable case-back allowing various ancillary options:
- Various power options
- Spare SD card storage
- Upgrades for future functionality - Interchangeable covers (allowing sub-branding/event-branding
- Full GPS functionality (real time clock, logging, waypoints, time etc.)
- On-board performance statistics logging (uploadable to PC)
- On-board route planning and waypoint establishment capability
- Map data sourced from Ordnance Survey at:
- 1:25,000 Explorer series
- 1:50,000 Landranger series
- Meridian 2 Vector mapping dataset - Full UK road maps available:
- Pre-loaded on Active 10 GPS unit
- Supplied as standard
- Vector map data type
- Highly detailed (minor roads; road names; rail, waterways, rivers and coastlines fully marked)
- Standard map colouration for ease of use - Maps on pre-loaded SD cards:
- All UK National Parks sold via retailers at launch - Two map scales on SD Cards: 1:25,000 and 1:50,000 map scale of each park - Raster map data type with full image reproduction - Maps sold as internet downloads:
- Specialist maps available from Satmap website
- Users can download onto their own blank SD cards - Multi-stage zoom and rapid pan facility
- Aerial photography/satellite imagery compatibility
- Maps overlaid with GPS data (‘You Are Here’ icon and ‘Snail Trail’ illustrating route taken)
- Gives access to over £5000 worth of software and mapping
- Route creation
- Upload/download
- Print map
- Route card
- Full GB 1:25k Explorer & 1:50 Landranger
- Global Satellite Imagery
- 3D photo imagery
- Route reviews
- Upload/download all routes
Rechargeable Battery Accessories
- 2700 mAh lithium polymer rechargeable battery
- Multi-head international wall charger
- AA standard back and battery cradle
- 1:25k Ordnance Survey Explorer Map
- Centred on map location of your choice
- Ordered directly from Satmap website
